S-J-5215X-5-25-0000

Pogo Pin Connectors


RoHS

S-J-5215X-5-25-0000Product image

Pogo Pin Connectors_5Pin_2.5mm Pitch_SMD Vertical_Water Proof Series

TechnologyWater ProofWorking Height5.7 mm
Plug/Rece(Male/Female)MaleRowSingle
BossW/ONumber of Pins5
Pitch2.5 mmSpring Force0.8N
Rated Current2ARated VoltageAC/DC 12V
Contact Resistance50mΩOperation Temp Range-40℃〜+85℃
Cycle Durability20,000 timesSoldering MethodSMD_Vertical
Compatible ProductS-J-2200X-5-25-0000CAPW/O
PackagingTape&ReelPackaging Quantity250pcs
