S-J-2200XL-5-25-0000

Mating Pad


RoHS

S-J-2200XL-5-25-0000Product image

Mating Pad_5Pin_2.5mm Pitch_SMD Vertical_Water Proof Series

S-J-2200XL-5-25-0000

TechnologyWater ProofWorking Height2.2 mm
Plug/Rece(Male/Female)FemaleRowSingle
BossW/ONumber of Pins5
Pitch2.5 mmRated Current2A
Rated VoltageAC/DC 12VContact Resistance50mΩ
Operation Temp Range-40℃〜+85℃Cycle Durability-
Soldering MethodSMD_VerticalCAPW/O
PackagingTape&ReelPackaging Quantity1,000pcs
