Right Angle Connector_3Pin_2.5mm Pitch_SMD Right Angle Series
| Technology | N/A | Working Height | - |
|---|---|---|---|
| Plug/Rece(Male/Female) | Male | Row | Single |
| Boss | W/O | Number of Pins | 3 |
| Pitch | 2.5 mm | Spring Force | 1.08N |
| Rated Current | 2 A | Rated Voltage | AC/DC 12V |
| Contact Resistance | 50mΩ | Operation Temp Range | -40℃〜＋85℃ |
| Cycle Durability | 20,000times | Soldering Method | SMD_Right Angle |
| CAP | W/O | Packaging | Tape&Reel |
| Packaging Quantity | 1,500pcs |
