S-J-7117R25-2-43-0000

Pogo Pin Connectors
Right Angle Connector

RoHS

S-J-7117R25-2-43-0000Product image

Right Angle Connector_2Pin_4.3mm Pitch_SMD Right Angle Series

TechnologyN/AWorking Height7.6 mm
Plug/Rece(Male/Female)MaleRowSingle
BossW/ONumber of Pins2
Pitch4.3 mmSpring Force1.08 N
Rated Current2ARated VoltageAC/DC 12V
Contact Resistance50mΩOperation Temp Range-40℃〜+85℃
Cycle Durability20,000 timesSoldering MethodSMD_Right Angle
CAPW/OPackagingTape&Reel
Packaging Quantity1,000pcs
Note
