| Technology | N/A | Working Height | 5.2mm |
|---|---|---|---|
| Working Range(Reference) | 4.9mm～5.5mm | Plug/Rece(Male/Female) | Male |
| Row | Single | Boss | W/O |
| Number of Pins | 1 | Pitch | Other |
| Spring Force | WH4.9mm<1.1N WH5.2mm 0.65N(Ref) WH5.5mm>0.4N | Rated Current | 2A |
| Rated Voltage | AC/DC 12V | Contact Resistance | 50mΩ |
| Operation Temp Range | -40℃〜＋125℃ | Cycle Durability | 20,000 times |
| Soldering Method | SMD_Right Angle | CAP | W/O |
| Packaging | Tape&Reel | Packaging Quantity | 8,000pcs |
