| Technology | N/A | Working Height | 3.5 mm |
|---|---|---|---|
| Working Range(Reference) | 3.3~3.8mm | Plug/Rece(Male/Female) | Male |
| Row | Single | Boss | W/O |
| Number of Pins | 2 | Pitch | 4.0 mm |
| Spring Force | 1.01N | Rated Current | 2 A |
| Rated Voltage | AC/DC 12V | Contact Resistance | 50mΩ |
| Operation Temp Range | -40℃〜＋85℃ | Cycle Durability | 20,000 times |
| Soldering Method | SMD_Vertical | CAP | W/O |
| Packaging | Tape&Reel | Packaging Quantity | 2,000pcs |
